Model: MHP15048A
4 Ton 48,000 BTU Split System Heat Pump
The MRCOOL 15 SEER Heat Pump Split System works diligently to make your home a comfortable space. This product gives you total energy efficiency with it's enhanced tube-and-fin coil design, allowing you to get more bang for your buck. You can have peace-of-mind with this product due to its affordability, quality, efficiency, and comfort. Look no further for your family's next home central heating and air system.
Key Features
- <ul><li>Louvered construction with baked polyester finish over galvanized steel to withstand bad weather</li><li>Raised coil to prevent debris blockage</li><li>CoolGuard advanced corrosion resistant coil</li><li>4-screw louver panels, corner-mounted controlsand 45-degree offset valves for easy service.</li><li>Enhanced tube-and-fin coil design featuring high efficiency heat transfer technology</li><li>Thread-on pressure switches for simple, quick replacement</li><li>Charged for 15 feet of line set</li><li>Heavy-duty compressor sound blanket forquiet operation</li><li>Internally protected against high temperature motor overload conditions</li><li>Ships with filter drier</li><li>All units ETL and ETLC approved and AHRI Certified</li><li>10 year registered parts warranty</li></ul>
Extra Information
| SEER | 15 |
|---|---|
| Max SEER | 14-15 |
| EER | 12 |
| HSPF | 8.2-8.5 |
| CFM | 1550-1600 |
| Tonnage | 4 |
| Cooling Capacity (BTU) | 47000 |
| Heating Capacity (BTU) | 45500-46000 |
| Voltage (V) | 208-230 |
| Phase | 1 |
| Cycle (Hz) | 60 |
| Stage | Single |
| Max Fuse Breaker (A) | 45 |
| Min Circuit Ampacity (A) | 29 |
| Refrigerant Type | R-410A |
| Refrigerant Volume (oz) | 161 |
| Decibel Rating (dBA) | 80 |
| Min Ambient Cool (°F) | 55 |
| Color | Gray |
| Color Family | Gray |
| Net Depth (in) | 32.25 |
| Net Height (in) | 37.00 |
| Net Width (in) | 32.25 |
| Net Weight | 273.00 |
| Restricted States | No |
| Registered Warranty | Registered 10 Year Parts Warranty |
| Base Warranty | 5 Year Parts Warranty |
Compatibility & Refrigerant
Verify match before ordering: Indoor and outdoor units must be designed for the same refrigerant generation. If replacing only one component, have an EPA-certified HVAC technician confirm compatibility before installation.
Important Notices
- Images are illustrative only; included accessories may vary by model.
- Availability, specifications, rebates, and pricing can change without notice.
Notices
- Image may not depict actual product color, inclusions, or accessories.
- Availability and substitutions are not guaranteed.
- Handling time: 3–5 business days.
Need Help Before Ordering?
Send us your model numbers (indoor + outdoor) and we’ll help verify compatibility before you purchase.
Frequently Asked Questions
Does MHP15048A require a specific refrigerant type?
Yes. This model is designed for R-410A. Always match indoor/outdoor components to the same refrigerant generation before installation.
What electrical requirements does MHP15048A use?
Check your jobsite power and breaker sizing before ordering. This model lists 208-230 / 1 Phase in the published specifications (verify local code requirements).
What capacity is MHP15048A?
4 Ton / 47000 cooling / 45500-46000 heating. Use a proper load calculation to select the correct size for your space.
Which series does MHP15048A belong to?
Signature Split Heat Pump. Confirm the system series when selecting matching components (indoor, outdoor, controls, accessories).
Does MHP15048A include a line set?
Line set length/specs vary by configuration. Published line set detail: 15, 25, 35, 50. Verify what’s included in your specific kit before purchase.
