Control Transformers

(Showing 2 of 2)
Class II Low-Voltage Power Supplies

HVAC Control Transformers

Source professional step-down Class II control transformers. Designed to safely convert high-voltage line power (120V, 208V, 240V, or 480V) into safe 24VAC low-voltage power for thermostats, control boards, relays, and safety limits. High-reliability power solutions for residential, commercial, and industrial HVAC applications.

ⓘ
Procurement & Sourcing Notice We help source commercial and residential control transformers from leading electrical component brands. Brand availability may vary by supplier, stock status, manufacturer policy, and product type. For multi-tap or specific VA rating requirements, contact us for cross-reference support.

Explore Sourcing Categories

Multi-Tap Transformers

Versatile step-down transformers featuring multiple primary voltage inputs (120/208/240V) to match any line-voltage source in the field. Ideal for service truck stock.

Contact Procurement Support

Foot & Plate Mount

Standard mounting configurations for easy installation inside air handlers, furnaces, and packaged unit control panels. Features robust terminal connections.

Contact Procurement Support

Hub-Mount Transformers

Features standard 1/2-inch electrical conduit hub mounting, allowing the transformer to be mounted directly to junction boxes for commercial applications.

Contact Procurement Support

Low-Voltage Control Power & Class II Safety Compliance

HVAC control transformers are step-down electromagnetic devices engineered to supply steady, low-voltage control power (typically 24VAC) to sensitive electronic components within an environmental system. By stepping down line voltage, these transformers isolate high-voltage power circuits from the user-facing thermostat and low-voltage safety limits, ensuring operational safety. To prevent electrical fires, these devices are certified as Class II transformers, meaning they are designed with internal impedance limits or integrated circuit breakers to restrict maximum power output if a short circuit occurs in the control wiring.

For professional B2B procurement, HVACProSales offers a full range of multi-tap and fixed-voltage transformers. When selecting a replacement transformer, technicians must verify the VA (Volt-Ampere) rating, which represents the maximum load capacity. A standard residential transformer is typically rated for 40VA. If auxiliary controls, zoning dampers, or high-draw contactors are added to the system, the control circuit's total current draw may exceed 40VA, causing the transformer to overheat and burn out. Upgrading to a 50VA or 75VA transformer with an integrated, resettable circuit breaker prevents downtime and simplifies troubleshooting.

B2B Sourcing Solutions

Service Technicians Stock multi-tap 40VA and 50VA transformers to quickly replace burned-out units across residential and light-commercial jobs.
Controls Contractors Source high-capacity 75VA and 100VA Class II transformers to power multi-zone dampers and building automation networks.
MRO Procurement Bulk-source standardized, foot-mounted electrical step-down transformers to support commercial facility maintenance teams.

Frequently Asked Questions

What does the VA rating on a transformer mean?

The VA (Volt-Ampere) rating represents the maximum power capacity the transformer can safely supply. To calculate the maximum amperage output of a 24VAC transformer, divide the VA by the voltage (e.g., a 40VA transformer can supply a maximum of 1.67 Amps: 40VA / 24V = 1.67A). Exceeding this draw will cause the transformer to fail.

Can I replace a 40VA transformer with a 50VA or 75VA transformer?

Yes. Upgrading to a higher VA rating (e.g., from 40VA to 50VA or 75VA) is highly recommended, especially if you are adding low-voltage accessories like smart thermostats, zoning dampers, or electronic air cleaners. The system will only draw the current it requires, and the larger transformer will run cooler and last longer.

What causes an HVAC transformer to burn out?

The leading cause of transformer failure is a low-voltage short circuit in the 24V control wiring (typically caused by a wire rubbing against sharp sheet metal, a failed contactor coil, or an insect shorting out a contactor terminal). Without a fuse or resettable circuit breaker in the circuit, a short will cause the transformer windings to melt within seconds.

Need Help Finding the Right Control or Component?

Our dedicated procurement support team is ready to assist you. Submit your equipment model number, serial number, or existing part specifications for rapid cross-referencing and quote support.
